Our technical experts will demonstrate how to optimally tune the simulation parameters for efficient and fast design in QForm for various metal forming processes.
QForm metal forming simulation software is implemented at commercial plants for economic benefit as well as at universities for academic and research purposes.
QForm Extrusion is designed for aluminum and magnesium profile extrusion simulation.
- Fully coupled task
- Analysis of tools
- Temperature taper for billet
- Force and temperature distribution during full process time
QForm Ring Rolling is specially designed software for ring and wheel rolling simulation and analysis.
- The program has a direct data preparation interface with the most popular ring rolling machines.
- Dual mesh method provides fast and accurate simulation.
QForm Extrusion Die Designer (QExDD)
is a system for creating parametric 3D design of tooling sets for solid and hollow profiles extrusion from 2D drawings.
- Die development automation;
- Bearing editor;
- QForm Extrusion integration;
Our technical experts will demonstrate how to optimally tune the simulation parameters for efficient and fast design in QForm for various metal forming processes.
«Metalloobrabotka 2021» – 21th International Specialized Exhibition for Equipment, Instruments and Tools for the Metalworking Industry that will take place at Expocentre Fairgrounds, Moscow, Russia
June 3, 2021: Possible defects in aluminium profile extrusion. Methods of their prediction and elimination based on numerical simulation;
Distortion estimation of extruded profiles during cooling using numerical simulation.
June 4, 2021: Automated optimization of die set elements based on simulation.
During the webinar you will learn:
During the webinar, the presenter explained the issues of importing geometry from CAD systems into the QForm. In most cases it is sufficient to use the automatic import and geometry meshing. If an automatic import is difficult, then the geometry can be diagnosed for errors and corrected in the QShape module or CAD system.
Congratulations to Mr. Kálmán Solti from Budapest University of Technology and Economics (Hungary) and Mr. Ivan Kulakov, from Bauman MSTU (Russia), who won the first place in the overall ranking! Mr. Kálmán Solti and Mr. Ivan Kulakov were awarded with a certificate of the Olympiad winner and a special prize – powerful personal computer.
We are glad to invite everybody who is interested in virtual manufacturing and simulation of metal forming processes to participate in summer school which will take place on August, 2021 in Moscow, Russia.
